F75fehtx
The Africa 4-stroke range, born from monitoring and Yamaha's long experience, has been specially developed to meet the extreme conditions of use. Power and reliability are the hallmarks of this range of engines in a field where Yamaha is the reference brand.
Technical Specifications
MOTOR
- Engine Type : 4 Stroke
- Start-up : Electric
- Max.Prop Shaft Horsepower (Kw) : 55.2 (75 hp)
DIMENSIONS
- Engine transom height (mm) : X : 643 (25.3 inch)
- Dry weight with propeller (kg) : 160
WARRANTY
- Manufacturer Warranty : 6 months or 100 hours
- Retail Network : Yamaha
Models available
F75HETX
F75FEHTX F75HETX
Technical Specifications
MOTOR |
|
| Architecture | L4 |
| Bore x Stroke (mm) | 81.0 X 88.9 |
| Displacement (cc) | 1832 |
| Engine Type | 4 Stroke |
| Fuel | Wet Sump |
| Fuel consumption (L/h-tr/min) | 28.7 L/h @6000 r/min |
| Full throttle operating range (tr/min) | 5000-6000 |
| Gear Ratio | 2.15 (28/13) |
| Ignition System | |
| Lubrication system | Unleaded |
| Max.Prop Shaft Horsepower (Kw) | 55.2 (75 hp) |
| Maximum Power (Kw) | |
| Number of Displacement | |
| Power system | 4 carburetors |
| Reduction ratio | 10.0 :1 |
| Reverse direction | Yes |
| Start-up | Electric |
| Steering Control | |
| Trim method (positions) | Continuously variable |
 MORE |
|
| Alternator | 35A |
| Control | Remote Control |
| Propeller Rotation | Clockwise |
DIMENSIONS |
|
| Dry weight with propeller (kg) | 160 |
| Engine Oil Capacity (L) | |
| Engine transom height (mm) | X : 643 (25.3 inch) |
| Oil capacity (L) | 3.2 L |
Equipments
REGULAR PROPELLER (3 blades) |
|
| Diameter | 13 1/2 |
| Material | ALUMINUM |
EQUIPMENT |
|
| Fuel Pipe Comp. | Yes |
| Remocon Control | Yes |
| Service kit assy. | Yes |
| Tachometer | Yes |
Gallery
Non-contractual images
